Scott Aerator - Boilermaker for Commercial and Residential Ponds

• 1 Float Platform
• 1 Motor Assembly
• 1 Stainless Steel Debris Shield
• Self Tapping Screws For Easy Assembly
• Industry Leading 5 Year Warranty

• Floating aerator for pond or lake
• 1/2, 3/4, 1, 1.5, 2, and 3 Horsepower available
• 115V or 230V for 1 HP and below, 230V required for 1.5 HP and above
• High flow rates with powerful aeration
• Approved for use in saltwater
• Designed for 24-hour-per-day operation
• Easy installation
• Maintenance free
• 4-Season Operation
• 5 Year Warranty

1/2 HP Unit

Recommended Pond Size : 1 acre

Minimum Water Depth : 36 Inches

Flow Rate : 24,000 gal/hr

Voltage : 115V or 230V

Amps : 115V - 8.2 Amps | 230V - 8.2 Amps

Watts : 115V - 670 Watts | 230V - 670 Watts

----------------------------------------

3/4 HP Unit

Recommended Pond Size : 1.25 acre

Minimum Water Depth : 36 Inches

Flow Rate : 27,000 gal/hr

Voltage : 115V or 230V

Amps : 115V - 11.5 Amps | 230V - 8.2 Amps

Watts : 115V - 680 Watts | 230V - 680 Watts

----------------------------------------

1 HP Unit

Recommended Pond Size : 1.5 acre

Minimum Water Depth : 36 Inches

Flow Rate : 30,000 gal/hr

Voltage : 115V or 230V

Amps : 115V - 10 Amps | 230V - 8.2 Amps

Watts : 115V - 680 Watts | 230V - 1210 Watts

----------------------------------------

1.5 HP Unit

Recommended Pond Size : 2 acres

Minimum Water Depth : 42 Inches

Flow Rate : 36,000 gal/hr

Voltage : 230V only

Amps : 10.6 Amps

Watts : 1780 Watts

 ----------------------------------------

2 HP Unit

Recommended Pond Size : 2.5 acres

Minimum Water Depth : 44 Inches

Flow Rate : 42,000 gal/hr

Voltage : 230V only

Amps : 12.6 Amps

Watts : 2280 Watts

----------------------------------------

3 HP Unit

Recommended Pond Size : 3 acres

Minimum Water Depth : 44 Inches

Flow Rate : 48,000 gal/hr

Voltage : 230V only

Amps : 14 Amps

Watts : 3000 Watts

LED Lights (Optional)

• Can be purchased now or added
  later. Light sets simply screw on to float.
• 2-light sets recommended for 1.5
  HP and below.
• 4-light sets recommended for 2 HP
  & 3 HP.

Color Changing LED Lighting Kit

• 2 or 4 light kits are available
• 110 Volts
• Durable exterior grade power
  supply
• 24 watts per fixture
• 1230 lumens
• 115V Timer Included
• Two-year warranty on the fixtures
  and brackets, one-year warranty on the transformer and power cord

White LED Fountain Lights

• 2 or 4 light kits are available
• 110 Volts
• 2800K Warm White
• Durable exterior grade power
  supply
• 9 watts per fixture
• 1230 lumens
• 115V Timer Included
• Two-year warranty on the fixtures
  and brackets, one-year warranty on the transformer and power cord

Timers (Optional)

• Can be purchased now or added
  later.
• Timers are only made to control
  fountains, not lights.
• The only difference between the
  residential and commercial 230V timers is the housing material—plastic for
  residential and metal for commercial.

115V Timer

• Dimensions: 5" H x 5½" W x
  3¾" D
• Construction: Outdoor-grade plastic case
• Power Cord: 3-ft, three-prong, grounded
  plug
• Timer Functionality: 24-hour timer, 23½-hour
  maximum On time
• Tripper Configuration: Two On and two Off trippers
  included; Dial accepts up to 12

230V Timer

• Amperage: 40 A
• Maximum Horsepower: 5 HP at 240V
• Maximum Cycles: 12 cycles
• Trippers: Includes two trippers for
  enhanced customization

115V & 230V (Dual Timer)

• Dual Timer Design: Contains two timers in one
  robust steel outdoor enclosure.
• Voltage Versatility: Perfect for 115V or 230V
  units, enhanced with compatible light sets.
• Easy Setup: User-friendly design for
  straightforward installation and programming.
• Scott Aerator Dual Timer Manual
  On/Off Levers: Clearly identified levers for manual control without affecting
  preset programs.
• Installation Flexibility: Includes knockouts for easy
  installation of switches or GFCI (not included).
• Mounting Hardware: Comes with all necessary
  hardware for quick and secure installation.
• Construction: Steel outdoor enclosure
• Voltage Compatibility: 115V or 230V units
• Dimensions: 10¼ inches (L) x 12 inches
  (W) x 4½ inches (D)

Motor & Pump : 5 Years

Non-Electric Fountain Components : 1 Year

Power Cable : 1 Year

Light Fixtures & Brackets : 2 Years

Light Transformer : 1 Year

Fountain Timers : 1 Year

BoilerMaker Assembly Instructions (pdf)

Scott Aerator BoilerMaker Anchoring method

We currently ship only to Lower 48 States of the United States. see Shipping Policy

Once you place an order, payment is pre-authorized and a confirmation with tracking will be emailed within 5–7 business days. Shipping may take longer during peak seasons due to manufacturer availability.

Items must be returned within 30 days after receiving your order. Items must be returned in the same condition in which they were received, be unused and include all the original packaging. see Refund Policy

Refunds are processed within 7 days from when we receive the item(s).

Question:

Can aeration maintain the health of my fish and clean my pond?

Answer:

Without a doubt. Whenever a pond needs to be cleared, the first step is aeration.

Question:

What is the best way to choose an aerator?

Answer:

Pond size and depth determine the right equipment: use surface aerators or fountains for ponds under 6 feet deep, and sub-surface aerators for ponds over 6 feet.

Question:

How do I get my aerator installed?

Answer:

Consult a licensed electrician if there's no power source by the pond. Aerators are easy to install once power is ready, and most customers successfully install them themselves to save money. Consider your available resources.

Question:

How should the aeration setup be configured?

Answer:

An ideal aeration setup combines a surface aerator or fountain with a sub-surface aerator to ensure thorough oxygen circulation throughout the pond.
